Spirax Sarco 1792190 FTC62-46 High Pressure Right to Left Flow Float and Thermostatic Steam Trap, 3/4 in Nominal, FNPT End Style, 0 to 425 deg C, 667 psig Pressure, Carbon Steel

Spirax Sarco Ball Float and Thermostatic Steam Trap, High Pressure Right to Left Flow, Series: FTC62-46, 3/4 in Nominal, NPT End Style, 190 mm Length, 667 psig Pressure, Carbon Steel, 0 to 425 deg C, 287.5 mm W x 239 mm H Dimensions

The FTC62 is a carbon steel bodied Ball Float Steam Trap having stainless steel working internals and automatic air venting facility.

The Spirax FTC62 Steam Trap must be installed with the direction of flow as indicated on the body (left to right, or right to left), and with the float arm in a horizontal plane so that it rises and falls vertically. It is also recommended to install a strainer upstream of the trap. The system must undergo regular maintenance to ensure the steam quality is to industry standard. Spirax Sarco FTC62 Steam Traps can be serviced without disrupting piping connections as long as it is fully isolated from both the supply and return lines. Any worn or damaged components should be replaced. Spirax FTC62 spare parts include a Body/Cover Gasket Kit, Strainer Screen and Gasket, Maintenance Kit, Overhaul Kit, and Air Vent Assembly with Air Vent Tube.
